520 Series 5MP Bullet IP Outdoor Camera, White
The 520 Series Bullet IP Camera is a low-profile, 5MP outdoor camera built for installers who need sharp 2K-class video without a bulky housing. Onboard AI analytics classify human, vehicle, and non-motor vehicle activity, filtering out the false motion alerts that make cheaper cameras a hassle to monitor, while smart IR delivers even, non-overexposed night viewing out to 30 meters.
Fast Setup and Remote Management with OvrC
Every 520 Series camera configures through OvrC, so installers can adjust image settings, set up recording, and manage the camera on-site or remotely. The camera also integrates with Control4 and other popular control systems.
Built-In Microphone and Audio I/O
An onboard microphone can be enabled or disabled remotely through OvrC, and dedicated audio input and output connections cover two-way audio and other surveillance audio needs.
Local Storage with Playback
A surveillance-rated SD card (not included, supports up to 256GB) provides local recording and redundancy at the edge, with playback of that footage available directly in the companion app.
Low-Profile, Weatherproof Housing
A compact, low-profile housing keeps the install discreet, and an IP67 rating with a -22°F to 140°F operating range holds up outdoors in nearly any climate.
Full Specifications
| Color | White |
| Warranty | 3 years |
| Image Sensor | 5MP (2592 x 1944) |
| Frame Rate | Up to 30 FPS |
| Lens | 2.8mm fixed, F1.6 |
| Field of View | Horizontal: 99.87° / Vertical: 70.36° |
| Minimum Illumination | 0.02 lux (AGC on); 0 lux with IR |
| IR Range | 20 - 30m |
| Wide Dynamic Range | 120dB, with highlight and backlight compensation |
| Dynamic Noise Reduction | 3D DNR |
| AI Analytics | Human, vehicle & non-motor vehicle detection; motion, line crossing, intrusion, and target counting |
| Streams | Main: up to 5MP H.265+ | 2nd: 704x480 H.264 | 3rd: 704x480 H.264 | 4th: 1920x1080 H.265/H.264/MJPEG |
| Microphone | Built-in, with audio input/output |
| SD Card Support | Up to 256GB |
| Network | PoE, IEEE 802.3af |
| Power Consumption | DC12V / PoE, <5.5-6W |
| Outdoor Rating | IP67 |
| Certifications | ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformant |
| Operating Temperature | -22°F to 140°F (-30°C to 60°C) |
| Dimensions | 167.5mm x 74.5mm x 74.5mm |
