520 Series 5MP 24/7 Color Turret IP Outdoor Camera, White
The 520 Series 24/7 Color Turret IP Camera stays in full color around the clock instead of switching to monochrome IR at night. A faster F1.0 lens and a built-in supplemental white LED bring in enough light for clear color video even in near-total darkness, and onboard AI analytics classify human, vehicle, and non-motor vehicle activity to cut down on false motion alerts.
Color at Night
Rather than relying on infrared and monochrome night video, the 24/7 Color models use a wide-aperture F1.0 lens paired with a supplemental white LED to hold full-color detail — useful for identifying clothing color, vehicle color, and other details that IR footage can't capture.
Fast Setup and Remote Management with OvrC
Every 520 Series camera configures through OvrC, so installers can adjust image settings, set up recording, and manage the camera on-site or remotely. The camera also integrates with Control4 and other popular control systems.
Local Storage with Playback
A surveillance-rated SD card (not included, supports up to 256GB) provides local recording and redundancy at the edge, with playback of that footage available directly in the companion app.
Low-Profile, Weatherproof Housing
A compact, low-profile housing keeps the install discreet, and an IP67 rating with a -22°F to 140°F operating range holds up outdoors in nearly any climate.
Full Specifications
| Color | White |
| Warranty | 3 years |
| Image Sensor | 5MP (2592 x 1944) |
| Frame Rate | Up to 30 FPS |
| Lens | 2.8mm fixed, F1.0 |
| Field of View | Horizontal: 97° / Vertical: 72° |
| Minimum Illumination | 0.006 lux (AGC on); 0 lux with supplemental white LED |
| Wide Dynamic Range | 120dB, with highlight and backlight compensation |
| Dynamic Noise Reduction | 3D DNR |
| Mounting Adjustment | Pan: 0°-360° / Tilt: 0°-75° / Rotation: 0°-360° |
| AI Analytics | Human, vehicle & non-motor vehicle detection; motion, line crossing, intrusion, and target counting |
| Streams | Main: up to 5MP H.265+ | 2nd: 704x480 H.264 | 3rd: 704x480 H.264 | 4th: 1920x1080 H.265/H.264/MJPEG |
| Microphone | Built-in, with audio input/output |
| SD Card Support | Up to 256GB |
| Network | PoE, IEEE 802.3af |
| Power Consumption | DC12V / PoE, <7W |
| Outdoor Rating | IP67 |
| Certifications | ETL Listed, CE, FCC, NDAA Compliant, ONVIF Conformant |
| Operating Temperature | -22°F to 140°F (-30°C to 60°C) |
| Dimensions | 94.6mm x 82.8mm |
